ASIC / SoC Turnkey

KeyASIC has been offering design and turnkey services since 2006, from the old 0.25um down to 16nm process technology.  The increasing complexity and functionality of today's ASIC and SoC have brought out much more challenges than the traditional chip implementation.  With 12 years of experience in IP, ASIC, SoC development, and semiconductor manufacturing, KeyASIC is one of the leading fabless design houses to help customers achieve their end target with a shorter time and lower investment.

At KeyASIC, we provide comprehensive ASIC/SoC design services with well-developed infrastructure and expertise in the industry.   Our objective is to meet the chip design needs of customers, accelerate their development process and deliver market-proven silicon products in the shortest time and at the lowest cost.  KeyASIC's professional ASIC/SoC design and production (OEM) approach offers a flexible engagement model.  The customer can gain control and ownership over the whole development process.  Customers may contract KeyASIC's ASIC/SoC turnkey services entirely or partially, without restrictions on business or volume size.

ASIC / SoC Design Services:

●     FPGA-to-ASIC conversion

●    Chip architecture design & RTL coding

●    Spec-to-GDSII, RTL-to-GDSII, Netlist-to-GDSII

●    Design-for-test (DFT), JTAG, Scan, ATPG, Memory BIST

●    Hardening of digital/mixed-signal IP

●    Automated Place & Route

●    IP (GDSII) merge

●    Logic cells power/timing characterization

●    Customization/optimization of Logic cells

●    Circuit & Layout customization & optimization

●    PDK development & validation

●    IP porting & validation


Foundry and Process Technology :


Package & Test Turnkey

As design complexity increases, packaging and testing represent a significant portion of the overall chip cost. KeyASIC works closely with industry partners to provide a wide selection of advanced and cost-effective packages and test offerings, such as high-speed interface, low power dissipation, a more excellent choice, and flexibility, translating to minimum cost for our customers.

Package Options

Partnering with leading first and second tier packaging partners like ASE and OSE, KeyASIC provides a wide range of package turnkey solutions from complex System-in-Package (SiP), Multi-Chip Module (MCM), Ball-Grid-Array (BGA) to the cost-sensitive legacy Quad Flat Pack (QFP) to satisfy customers' increasing demands for smaller sizes, more I/Os, and lower costs.

Testing Program and Test Environment

Test program and environment prepared for each ASIC prototype are developed and monitored carefully by a group of experienced in-house engineers. At the mass production stage, when all of the settings of a test program are confirmed, the test program and the production documents are sent to our test partners to ensure accuracy before production begins. Only after careful verification, will the test program be formally released to our test partner. Various tester choices are supported for different performance/cost requirements through qualified outside partners who meet customers' capacity and cost objectives.

Production Turnkey

KeyASIC is fully committed to providing our customers with manufacturing flexibility, optimal value, quickest time-to-market silicon solutions, and a dedication to customer service with our unique one-stop production management expertise.

Design services
